Gazelle Bikes Arroyo C8 HMB Elite

The Gazelle Arroyo C8 HMB Elite offers a joyful introduction to the best of both bike worlds: an easy, elegant Dutch-style bike and a masterfully designed machine that beautifully integrates with Bosch e-bike technology. Featuring an approachable low-step frame, relaxed geometry, and best-in-class components, the Arroyo C8 is a capable all-rounder for trips of any type or duration, thanks to a powerful motor, high capacity battery, and thoughtful accessories.
- Battery Recharge Time: 3-4 hours
- Max Assisted Speed: 20 mph
- Range: 40 - 80 miles
Geometry
Sizes:
Frame Size
Small (46)
Medium (53)
Large (57)
Standover (mm)
436
436
436
Effective top tube length (mm)
571
593
605
Head tube angle (°)
68.5
68.5
68.5
Effective seat tube angle (°)
69.5
69.5
69.5
Chainstay length (mm)
482
482
482
BB drop (mm)
60
60
60
Head tube length (mm)
145
165
165
Fork length (mm)
475
475
475
Fork offset (mm)
55
55
55
Wheelbase (mm)
1097
1120
1131
Stack (mm)
621
640
640
Reach (mm)
339
354
366
Sizing
Sizes:
Frame Size
Height (inches)
Height (cm)
Small
4'10” - 5’6”
155 - 165cm
Medium
5’6” - 5’10”
164 - 174cm
Large
5’10” - 6’3”
172 - 182cm
